- Body is of brass construction and is designed to conform to BS EN 200
- Unique patented technology
- Designed with the installer in mind to ensure installation and future maintenance is made quick and easy
- Supplied with flexible connecting pipes
- Chrome plated to BS EN 248
- WRAS Approval number: 1609025
- Product Type: Twin Lever Monobloc Tap
- Finish: Chrome
- Primary Material: Brass
- Plating Material:
- Material Details:
- Durability: Rust Resistant
- Mounting Location: Deck Mounted
- Number of Installation Holes: 1
- Number of Installation Holes (Integer): 1
- Spout Type: Gooseneck/High Arc
- Swivel Spout: Yes
- Maximum Flow Rate (Litres): 42.5
- Minimum Water Pressure (Bars): 0.3
- Water Saving: No
- Maximum Water Pressure (Bars): 5
- Instant Boiling Water Tap: No
- LED Light: No
- Spray Included: No
- Spray Type:
- Lock Technology:
- Spray Head Functions:
- Spray Function Activation:
- Pre-Rinse Spout:
- Compatible with a sprayer:
- Handle(s) Included: Yes
- Number of Handles: 2
- Compatible Handle Part Number:
- Compatible Deck Plate Part Number: Not Applicable
- Waste Included: No
- Soap Dispenser Included: No
- Compatible Soap Dispenser Part Number: Not Applicable
- Water Filtration Included: No
- Supply Lines Included: Yes
- Type of Tap Tails Included: Flexi Pipe
- Hot Water Tank Included:
- Compatible Kitchen Sink Part Number: Not Applicable
- Power Supply Required: No
- Power Supply Unit Included:
- Cartridge Type: Ceramic Disk Cartridge
- Number of Turns: 1/4
- Plug Included: No
- Plug Type:
- Adapter Type:
- Style: Modern & Contemporary
- Country of Origin: China
- Compatible Drain Assembly Part Number: Not Applicable
- Compatible Filtration System Part Number:
- Compatible Water Tank Part Number:
- Activation technology: No
- Sensor functions:
- Automatic Shutoff:
- Activation technology OLD: Handles
- Pieces Included:
- Product Care: Your fitting has a high quality finish and should be treated with care to preserve the visible surfaces. All surfaces will wear if not cleaned correctly, the only safe way to clean your mixer tap is to wipe with a soft damp cloth. Stains can be removed using washing up liquid. All bath cleaning powders and liquids will damage the surface of your fitting, even the non - scratch cleaners. Note: Never use abrasive detergents or Note: disinfectants or those containing alcohol, hydrochloric acid or phosphoric acid.
- Handle Style: Lever
- Are you CE Certified?:
- EU Economic Operator Information:
- ASME A112.18.2 Compliant:
- ASME A112.19.1 Compliant:
- ASME A112.19.2 Compliant:
- UL Listed:
- ADA Compliant:
- ASME A112.19.3 Compliant:
- ASSE 1001 Certified:
- WRAS Approved: Yes
- ASSE 1016 Certified:
- ISTA 1A Certified: No
- ISTA 3A or 6A Certified: No
- BS 476 Compliant:
- FIRA Certified:
- ISO 14000 Certified:
- GSA Approved:
- WEEE Recycling Required: No
- ISO 14001 Certified:
- ISO 9000 Certified:
- ISO 9001 Certified:
- California AB 1953 Compliant:
- NSF/ANSI 61 Certified:
- WQA Gold Seal Certified:
- ASME A112.18.1 Compliant:
- CSA Certified:
- cUL Listed:
- CALGreen Compliant:
- cUPC Certified:
- UL 1951 Listed:
- UPC Certified:
- ASME A112.18.1/CSA B125.1 - 2018:
- IAPMO Certified:
- Vermont Act 193 Compliant:
- TÜV Rheinland Certified:
- Energy Policy Act 1992 Compliant:
- Low Lead Compliant:
- Stiftung Warentest Note:
- Energy Star Compliant:
- Are you UKCA Certified?:
- UK Economic Operation Information:
- General Product Safety Directive Compliant: Yes
- REACH (Registration, Evaluation, Authorisation and Restriction of Chemicals) Compliant: Yes
- UK Water Supply and Water Fitting Compliant: Yes
- TMV2 (Thermostatic Mixing Valve) Scheme Compliant: No
- Valve type: 1.27cm C D valves 1/4 turn
- Inlet connections: M10 1.27cm BSP Flexible tails with isolation valves
- Spout/Faucet Height - Top to Bottom: 34.6
- Overall Tap Width: 16.5
- Overall Tap Depth: 23.5
- Spout Reach - Front to Back: 23.5
- Spout Height - Top to Bottom: 22.8
- Overall Product Weight: 2.04
- Installation Hole Diameter: 3.6
- Maximum Deck Thicknes
