Danfoss Ras-b2 Dynamic Radiator Packs Trv & Lockshield Valve With 10mm Fittings

Danfoss RAS-B2 radiator valve is a pressure-independent radiator valve, designed for use in 2-pipe heating systems. RAS-B2 dynamic valves are fitted with a flow-limiting device for presetting the maximum water flow. The valves are available with a maximum water flow of 10 - 135 l/h. RAS-B2 has a built-in pressure regulator, which keeps the differential pressure over the valve at a constant level of 0.1 bar, maintaining the set flow. Dynamic valves are supplied with a protective cap, which can be used for manual regulation during the construction phase.The protective cap must not be used as a manual shut of the device. A special manual shut-off device (code no. 013G5002) should be used. To be able to distinguish between other valve bodies of the Danfoss RA series the RAS-B2 protective cap and presetting ring are green. RAS-B2 valve bodies are manufactured from brass with nickel plating. The gland seal pressure pin is chromium steel and works in a lifetime lubricated O-ring. The complete gland seal assembly can be replaced without draining down the system.Combining a radiator thermostat and an automatic hydronic balancing valve in a single product enables you to significantly increase the efficiency of your clients’ heating systems regardless of whether the system is operating at full load (Winter) or partial load (Spring/Autumn).You will find RAS-B2 simple to work with. Installation is the same as a standard TRV, whilst commissioning the heating system is made simpler and can be performed in a fraction of the time. Once installed, the valve ensures constant hydronic balancing, 24 hours a day, 365 days a year.The valve permanently optimises the heating system in terms of accurate room temperature control. It also provides automatic hydronic balancing during unexpected system resistance, changing occupant behaviour or fluctuations in weather conditions.Specifications:Connection type to valve: RADesign: AngleRLV type: RLV-DSensor design: RAS-C2Sensor media: LiquidSensor setting temperature [°C] [Max]: 28 °CSensor setting temperature [°C] [Min]: 8 °CSensor type: Built-in sensorType RAS-C2 + RA-DV + RLVValve size: 10 mmValve type: RA-DVBox Contains:1x RAS-C2 sensor1x 10 mm Angle automatic balancing valve1x Lockshield valve
